Nomadic Cooling X2 – 12V Low-Profile Rooftop Air Conditioner

Upgrade your van, camper, or off-grid build with the Nomadic Cooling X2 (24V)—a compact, lightweight, and highly efficient rooftop air conditioner engineered for serious van life comfort. Built with a low-profile aerodynamic shroud and a whisper-quiet ventilation system, the X2 delivers powerful cooling performance while maintaining one of the smallest footprints in the industry.

Designed to fit a standard 14" × 14" roof opening, the X2 installs easily on most vans, including Sprinter, Transit, and ProMaster platforms. With five operating modes and adjustable vents, users can fine-tune airflow and efficiency to match any climate or travel style.

Key Features

• Lightweight Yet Powerful Cooling

  High-performance 24V cooling system in a compact 44 lb design.

• Low-Profile Aerodynamic Shroud

  Reduces drag and wind noise while keeping a sleek roofline.

• Standard 14×14" Opening Fitment

  Makes installation straightforward and compatible with most conversion vans.

• Quiet Fan & Adjustable Vents

  Provides smooth, controlled airflow with minimal noise.

• Five-Mode Control Panel

  Offers precise control for comfort and energy efficiency.

• Efficient 24V Operation

  Optimized for lithium battery systems and off-grid builds.

• Optional 1-Year Extended Warranty

  Additional protection for long-term reliability.

Technical Specifications

• Model: X2 – 12V

• Rated Cooling Capacity: 10,280 BTU

• Rated Power: 900W

• Current Draw:

  • Eco Mode: 27A

  • Max Mode: 55A

• Refrigerant: R134a

• Refrigerant Oil: POE68

• Unit Weight: 44 lbs

• Dimensions: 28.0" × 22.5" × 6.9"
