Opti-Rate Striker 4x4 2" lift kit (complete) - Sprinter 2500 ,2015-2018 - Van Compass

The Van Compass OPTI-RATE STRIKER 4x4 2" Lift Kit (7035-OPTI) is designed for 2015–2018 Mercedes-Benz Sprinter 2500 4x4 Single Rear Wheel (SRW) vans, providing increased ground clearance, larger tire clearance, and enhanced suspension control for overland and heavily equipped conversion builds. The Opti-Rate system allows the rear spring rate and ride height to be tailored to the vehicle's weight and configuration, making it particularly well suited to builds weighing approximately 9,000–10,000 lb and above, while maintaining factory suspension geometry.

FEATURES

• 2" lift — Increases ground clearance and allows tires up to 35 × 12.50 with appropriate wheel offset and minimal fender trimming.
• Opti-Rate system — Adjustable rear spring rate and ride height to match the vehicle's weight and configuration.
• Preserved suspension geometry — Front subframe spacers maintain CV joint, tie rod, and control arm geometry within factory operating limits.
• Optimized rear suspension — 2" lift block, extended sway bar links, shock relocation brackets, and bump stop extensions improve articulation and prevent excessive compression or extension.
• Heavy-duty construction — Precision-engineered components proudly made in the USA.

KIT INCLUDES

• 2" front strut spacers
• 2" front subframe drop spacers
• 2" engine & transmission mount lift spacers
• CNC-machined 2" steering shaft extension
• Low-pressure power steering hose extension
• Front brake line relocation brackets
• Opti-Rate rear leaf spring pack with adjustable spring rate and ride height
• 2" rear lift block
• Extended rear sway bar links
• Rear lower shock relocation brackets
• Rear bump stop drop brackets
• Wind assist/headlight leveling sensor bracket
• Complete hardware and detailed installation instructions
