Transit Pistol Wheel Well Water Tank (16 Gallon)
Features:
Maximizes garage storage space with its slim design, fitting around the Transit's wheel wells Specifically designed to fit the Transit's wheel wells, offering food-grade and BPA-free construction approved for use in the US and Canada Symmetrical design accommodates placement on both driver and passenger sides; includes a comprehensive fresh water fittings kit, saving time and trips to the plumbing store
100% original guarantee
Return within 30 days
Free delivery on most orders
This tank perfectly fits around the wheel well of your Transit and takes up no addition width - maximizing your garage space!
Made with BPA-free, food-grade (CSA approved) polyethylene, not only do these tanks save space and provide a good amount of safe drinking water, they also insulate your wheel well to keep the road noise down.
Looking for a grey water tank to compliment your freshwater tank? Check out our 17 Gallon Undermount Tank! The undermount tank fits snugly under the drivers side of your Transit's framed undercarriage. It's the perfect solution for your off-grid water requirements.
Key Features & Benefits:
- Slim design - Sacrifices ZERO space in your garage.
- Space Saving - A unique way to make efficient use of that awkward wheel well area and shape.
- Build Options - These tanks are interchangeable between both wheel wells. You can fit this tank over whichever wheel well works best for your build. Need more water? Place one on either side of your van for mega-volume!
- Distributes Weight - Adds weight over your rear axle to help increase traction if you get in a sticky spot. No more slips and skids, not to mention unwanted wheel wear, thanks to the perfect weight distribution of these tanks.
- Sound Proofing - When it comes to road noise, these tanks step it up with added noise reduction around your wheel well.
- BPA-Free and Food Grade Approved - Feel safe knowing these tanks are food grade CSA approved! Wash the dishes, have a shower, fill the dog bowl, and stay hydrated, while exploring in your van!
- Fittings Kit Add-On Available - Save yourself the headache and multiple trips to the plumbing store when you bundle this tank with our Freshwater Fittings Kit!
- Strapping Kit Add-On Available - Weather-resistant strapping crafted from heavy-duty 1/8" thick, 1 1/2" wide aluminum. Simple and secure!
- Water Level Sender & Gauge Kit Add-On Available - This water tank has a fitting specifically designed for use with the KUS S5U Water Level Sender!
- Compatible - Pairs well with our 17 Gallon Undermount Tank!.
- Dimensions & Specifications:
Designed for the all Transit wheelbases.
Tank can be placed on either the PASSENGER SIDE or DRIVER SIDE of the van.
Fits around the wheel well with or without flooring installed in the van.
Tanks are made from linear low-density polyethylene.
Food grade CSA approved and BPA free - safe for freshwater use!
16 US Gallons / 60.5 Litres
41” 8.5” 21” (Length x Width x Height)
1 x 1 ½” drill-out membrane port (on top)
1 x 1 ¼" drill-out membrane port (on top)
1 x 1 ¼" drill-out membrane port (on side)
1 x ¾" ports (on side)
2 x ½” ports (on side)
The larger 1 ¼" ports are "membrane ports", which require drill-out for use.
The membrane eliminates the need to plug the ports if you don't use them.
All ports are NPT female-threaded.
Fresh Water Fittings Kit Add-On:
- 1x 1 ¼" PVC 90
- 2x ¾" PVC 90
- 1x ¾" PVC Ball Valve
- 1x ¾" Nipple - 6" long
- 1x ¾" Nipple - 4" long
- 1x ¾" Nipple - 1 ½" long
- 1x ½" Poly Adaptor
- 2x ½" Poly Elbows
- 2x #20 Hose Clamps
- 2x #8 Hose Clamps
- 1x Roll of Teflon Tape
- 1x Fill Port
- 5ft Fill Hose
- 5ft ⅝" ID Vinyl Hose
Aluminum Strapping Kit Add-On:
- Specifically designed for your Transit Pistol Wheel Well Water Tank
- Kit includes 2x Heavy-Duty Aluminum Straps & Aluminum Mounting Hardware
Weight & Dimensions
| Length x Width x Height | 41” x 8.5” x 21” |
| Dry weight | 9.4 lbs (tank only) |
| Water capacity | 16 Gallons / 133.44 lbs |
| Total weight (full tank) | 142.4 lbs |
| Straps and hardware weight | 4 lbs |
| Total weight (full tank + straps and hardware) | 146.84 lbs |
Specifications
| Length x Width x Height | 44” x 8.5” x 21” |
| Volume | 16 US Gallons / 60.5 Litres |
| Drill-out membrane port (on top) | 1 x 1 ½" |
| Drill-out membrane port (on top) | 1 x 1 ¼" |
| Drill-out membrane port (on one end) | 1 x 1 ¼" |
| Ports (on one end) | 1 x ¾" |
| Ports (on one end) | 2 x ½" |
Compatibility
Designed for the all Transit wheelbases.
Tank can be placed on either the PASSENGER SIDE or DRIVER SIDE of the van.
Fits around the wheel well with or without flooring installed in the van.
FAQ
Can I add fittings to my water tank?
We can't add any additional fittings to your tank as they are made in batches. The fittings are spin welded on requiring specialized equipment. There is likely a spin welder in your local area that can add additional fittings for you if needed.
What is the water tank wall thickness?
The standard wall thickness of our water tanks is approximately 3/16”.
Is this tank compatible with a water level sensor?
Yes! Check out our KUS Water Level Sensors and Gauges.
What is the total weight of the 16-gallon pistol tank when full, including straps and hardware?
The empty tank weighs 9.4 lbs. With 16 gallons (133 lbs) of water, it weighs about 142.4 lbs. Adding the 4 lbs for straps and hardware, the total weight is around 146.4 lbs.
Installation instructions:
| Freshwater Fittings Kit | None or With |
| Strapping Kit | Without or With |
