Transit Pistol Wheel Well Water Tank (16 Gallon)

Transit Pistol Wheel Well Water Tank – 16 Gallon

Features

• Maximized Storage: Slim profile fits snugly around Transit wheel wells without sacrificing garage space.
• Versatile Fit: Symmetrical design allows installation on either the driver or passenger side.
• Safe Water Storage: Constructed from food-grade, BPA-free polyethylene (CSA approved for use in the US and Canada).
• Bundled Convenience: Optional Fresh Water Fittings Kit saves time and eliminates extra trips to the hardware store.

Product Description

The Transit Pistol Wheel Well Water Tank is the ultimate space-saving solution for van conversions. Designed specifically for all Ford Transit wheelbases, this 16-gallon tank wraps around your wheel well without consuming additional garage space. Whether placed on the driver or passenger side, its slim, symmetrical shape allows for flexible installation.

Crafted from BPA-free, food-grade polyethylene approved in both the US and Canada, this tank safely stores drinking water for off-grid adventures. It also acts as an effective sound barrier, helping reduce road noise in your van.

Pair it with our 17-gallon undermount grey water tank for a complete plumbing setup.

Key Benefits

• Garage Space Saver – Ultra-slim design preserves usable cargo space.
• Dual-Side Fitment – Install over either wheel well or double up for more capacity.
• Better Weight Distribution – Adds balanced weight over the rear axle for enhanced traction.
• Noise Reduction – Insulates the wheel well to help cut road noise inside the van.
• Trusted Material – Food-safe, BPA-free, CSA-approved polyethylene.
• Easy Add-On Options – Compatible fittings, straps, and gauge kits available.
• Sensor Ready – Built-in port for the KUS S5U Water Level Sender.

Specifications

• Capacity: 16 US Gallons / 60.5 Litres
• Dry Weight: 9.4 lbs
• Full Weight (with fittings/straps): Approx. 146.8 lbs
• Dimensions (L x W x H): 41” x 8.5” x 21”
• Material: Linear low-density polyethylene
• Approved Use: Food-grade, CSA-certified, BPA-free
• Fitment: Driver or passenger side, all Transit wheelbases, with or without flooring

Port Configuration

• Top Ports:
  • 1 x 1 ½” drill-out membrane port
  • 1 x 1 ¼” drill-out membrane port
• Side Ports:
  • 1 x 1 ¼” drill-out membrane port
  • 1 x ¾” port
  • 2 x ½” ports

All ports are NPT female-threaded. Membrane ports allow optional use without requiring plugs.

Add-On Kits

Fresh Water Fittings Kit

Includes elbows, valves, nipples, plugs, hose clamps, fill hose, Teflon tape, and more.

Aluminum Strapping Kit

• 2x Heavy-duty 1/8" thick, 1½" wide aluminum straps
• Mounting hardware included

Water Level Sender Kit

Compatible with KUS S5U sensors and gauges for accurate water monitoring.

FAQ

Can I install extra fittings?

No. The tanks are made in batches and use spin-welded fittings. Consult a local specialist if additional fittings are required.

What is the wall thickness?

Approximately 3/16”.

Is it sensor-compatible?

Yes, compatible with KUS S5U Water Level Sender and Gauge kits.
