Opti-Rate Striker 4x4 2" lift kit (complete) - sprinter 2500 ,2019-2022 - Van Compass

⚠️ SPECIAL ORDER Manufacturing times may vary. Please contact us for more information. NON-EXCHANGEABLE / NON-REFUNDABLE

The Van Compass OPTI-RATE STRIKER 4x4 2" Lift Kit (7057-OPTI) is designed for 2019–2022 Mercedes-Benz Sprinter 2500 4x4 vans, providing increased ground clearance, improved suspension articulation, and clearance for larger tires. Designed for heavy-duty conversions, overland rigs, and fully equipped adventure vans, the Opti-Rate rear spring system allows the ride height and spring rate to be tuned to the vehicle, making it particularly suitable for heavier builds in the 9,000–10,000 lb+ range. With the proper wheel offset and minor fender trimming, the system can accommodate tires up to 35 × 12.50.

FEATURES

• 2" suspension lift — Increases ground clearance, tire clearance, and off-road capability.
• Opti-Rate rear leaf springs — Tunable ride height and spring rate for heavier vehicle configurations.
• Maintains factory geometry — Precision-machined front subframe spacers preserve proper CV joint, tie rod, and control arm alignment.
• Improved rear articulation — 2" lift block, extended sway bar links, shock relocation brackets, and bump stop extensions help prevent binding and bottoming out.
• Heavy-duty construction — Precision-engineered components proudly made in the USA.

KIT INCLUDES

• 2" front strut spacers
• 2" front subframe drop spacers
• 2" engine & transmission mount lift spacers
• CNC-machined 2" steering shaft extension
• Low-pressure power steering hose extension
• Front brake line relocation brackets
• Opti-Rate rear leaf spring pack
• 2" rear lift block
• Extended rear sway bar links
• Rear lower shock relocation brackets
• Rear bump stop drop brackets
• Wind assist/headlight leveling sensor bracket
• Complete hardware and detailed installation instructions
