Striker AWD 2" lift kit (complete) - Sprinter (2023+) 2500 Single Rear Wheel - Van Compass

⚠️ SPECIAL ORDER Manufacturing times may vary. Please contact us for more information. NON-EXCHANGEABLE / NON-REFUNDABLE

The Van Compass STRIKER AWD 2" Lift Kit is designed for 2023+ Mercedes-Benz Sprinter 2500 AWD Single Rear Wheel (SRW) vans, providing a true 2" suspension lift, increased ground clearance, and improved suspension articulation for off-road use. The front subframe relocation system maintains proper CV joint, tie rod, and control arm geometry, while the upgraded rear suspension improves articulation and ride height. With the correct wheels and minor fender trimming, the system supports tires up to 35 × 12.50.

FEATURES

• True 2" lift — Increases ground clearance and off-road capability while maintaining factory suspension geometry.
• Optimized front geometry — CNC-machined and precision-welded subframe spacers maintain proper CV, tie rod, and control arm positioning.
• 6-leaf rear Mini Leaf Spring Pack — Increases rear ride height and suspension articulation.
• Complete rear suspension hardware — Includes extended sway bar links, shock relocation brackets, and bump stop spacers.
• Up to 35 × 12.50 tires — Requires appropriate wheels and minor fender trimming.
• Wheel clearance requirement — 2023+ AWD models require wheels with 6" backspacing or less; 17" × 8" +38mm is given as an example. Wheels with greater backspacing or higher offsets may contact the shock reservoir.

KIT INCLUDES

• 2" front strut spacers
• 2" front subframe drop spacers
• 2" engine & transmission mount lift spacers
• Front differential re-clocking cams
• CNC-machined 2" steering shaft extension
• Low-pressure power steering hose extension
• Front brake line relocation brackets
• 6-leaf Mini Leaf Spring Pack
• Extended rear sway bar links
• Rear lower shock relocation brackets
• Rear bump stop drop brackets
• Wind assist/headlight leveling sensor bracket
• Complete hardware and detailed installation instructions

2023+ VS30 AWD Striker 2" Front Kit Installation Instructions

2019+ VS30 4x4 and AWD Striker 2" Rear Kit Installation Instructions

Video: Van Compass STRIKER AWD 2" LIFT KIT (COMPLETE) - Sprinter AWD (2023+) 2500 SINGLE REAR WHEEL
