Victron Energy 12/1200 120V VE.Direct NEMA GFCI Phoenix Inverter
100% original guarantee
Return within 30 days for most orders
Free delivery on most orders
Pure Sine Wave Inverter – Reliable AC Power from 12V/24V/48V DC Batteries
Power household appliances requiring 230V or 120V AC using your leisure or automotive battery system (12V, 24V, or 48V DC). Ideal for off-grid, RV, marine, and backup applications.
Key Features
✔ VE.Direct Communication Port
Connect to:
- Computers (via VE.Direct to USB interface)
- Smartphones, tablets, or MacBooks (via VE.Direct Bluetooth Smart Dongle)
✔ Customizable Settings
- Low battery alarm and cut-off thresholds
- Restart levels and dynamic load-dependent cut-off
- Output voltage range: 210–245V
- Selectable frequency: 50 Hz or 60 Hz
- ECO mode toggle and sensitivity adjustment
✔ Real-Time Monitoring
Track:
- Input/output voltage
- Load percentage
- Active alarms
✔ Proven Reliability
Built with full bridge plus toroidal transformer topology for long-term durability.
Short-circuit and overheat protection included.
✔ High Start-Up Power
Handles demanding loads such as:
- LED power converters
- Halogen lamps
- Power tools
✔ ECO Mode
Reduces power draw by switching to standby under light load (<15W).
Wakes periodically (default: every 2.5 seconds) and resumes operation if load increases.
✔ Remote On/Off Capability
Supports external switch via two-pole connector.
✔ LED Diagnostic Indicators
Refer to the manual for detailed LED signal explanations.
✔ Easy DC Connection
Screw terminals allow simple, tool-free installation.
Optional Accessory
Filax Automatic Transfer Switch – Ideal for low-power inverters
Seamlessly switches between inverter and AC grid power in under 20 ms to prevent interruption for sensitive electronics.
