Victron Energy MultiPlus 12/2000/80-50 120V VE.Bus (UL Certified) Inverter/Charger

Reduce power consumption of an inverter in standby

The Victron Energy MultiPlus 12/2000/80-50 combines a pure sine wave inverter, adaptive battery charger, and automatic transfer switch in one unit. Designed for 12V battery systems, it supplies 120V AC power for RVs, marine applications, and off-grid installations, with intelligent power management and automatic switching to battery power when external AC power is interrupted.

FEATURES

• DC input voltage: 12V

• AC output: 120V, 60Hz

• Continuous output power: 1600W at 25°C; 1400W at 40°C; 1000W at 65°C

• Peak power: 3500W

• Battery charging current: 80A

• AC input: One 120V input

• Transfer switch: Integrated, 50A

• AC outputs: Two 120V outputs

  • Main output: Automatically switches to inverter power when external AC power is interrupted, with a transfer time under 20ms

  • Auxiliary output: Powers selected loads only when external AC power is available

• PowerControl: Helps prevent overloads by managing the available shore or generator current

• PowerAssist: Supplements limited external AC power with battery power during periods of high demand

• Adaptive charging: Adjusts the charging process to help optimize battery performance

• Communication: VE.Bus port for system monitoring and integration

• Expandable system: Supports up to six units in parallel and compatible three-phase configurations

• Battery charging: Includes a secondary output for charging a starter battery, limited to 1A

• Protection: 300A DC protection

• Certification: UL 458

DIMENSIONS AND WEIGHT

• Dimensions (H × W × D): 19.9 × 9.3 × 5.8 in (506 × 236 × 147 mm)

• Weight: 34.2 lb (15.5 kg)
