Broad Arrow Curved Window 497×497

Customers must use the cutout template below prior to ordering their window to ensure the window will fit properly and work with their build.

Broad Arrow Square Dual-Glazed Cassette Window (497 x 497 mm)

The Broad Arrow Square Dual-Glazed Cassette Window is a DOT-approved van conversion window designed for improved insulation, privacy, and integrated shading. Its slightly curved acrylic construction helps it better conform to van body contours, delivering a cleaner exterior finish and more reliable sealing performance.

This cassette-style window includes an integrated bug screen and pleated blind system, combined with a durable aluminum frame for long-term strength. It is intended for camper vans and conversion builds where precise template-based installation is required.

Features

• Dual-glazed acrylic construction for insulation and durability

• Cassette-style system with integrated bug screen and pleated blind

• Slightly curved design to better match van body contours

• Aluminum frame for strength and corrosion resistance

• DOT-approved glazing for compliance and safety

• Includes wooden mounting ring for installation support

• Designed for wall thickness: 26–50 mm

• Visible light transmission: 10%

• Manufactured in China

Specifications

• Window type: Square Dual-Glazed Cassette Window

• Size (W x H): 497 x 497 mm

• Cut-out size: 500 x 500 mm

• Overall size: 527 x 527 mm

• Interior blind size: 527 x 540 mm

• Glass type: Acrylic Dual Glazed

• Frame material: Aluminum

• Wall thickness compatibility: 26–50 mm

• Light transmission: 10%

• Country of manufacture: China

• Certification: DOT Approved

Compatibility & Installation

• Requires precise cut-out using template before installation

• Designed for camper van side wall applications

• Suitable for sliding door installations, but clearance must be verified

• Interior cassette system may interfere with bed pods, flares, or interior/exterior extensions

• Acrylic curvature may vary slightly due to manufacturing process, without affecting sealing or performance

• Not equivalent to tempered glass due to flexible acrylic construction
